MEA® HDPE Grease Separator
- Model: GS-5H
- Two-Stage Separation
- Level Sensor Control
The MEA® Full Disposal Grease Separator features an integrated cleaning device and agitator, manual/automatic control, and an enclosed design to prevent odors. Double sightglasses enable easy monitoring, while the patented easy-clean design ensures simple operation and low maintenance.
Specifications
| Model No. | GS-5H |
| Nominal Size | 5 L/S |
| Inlet DN | 160 mm |
| Outlet DN | 160 mm |
| L1 | 2428 mm |
| H1 | 1895 mm |
| H2 | 1705 mm |
| W | 1840 mm |
| Volume | 1500 mm |
| Empty Weight | 275 kg |
| Full Weight | 1775 mm |
| Min Mounting Size | 3300*2600 |
For comprehensive information, please see the document available for download below.
-
Description
Product Characteristics
- HDPE, 12mm wall thickness, integrated molding
- Enclosed running, no odor
- Two-stage separation, automatic sludge removal
- Large sludge separation chamber with multiple overflow points
- Large blade spiral separation, handles 5–180mm sludge
- Spiral device with reverse blades for squeezing
- Optional automatic oil discharge, max 25L/h
- Automatic heating, constant temperature mode
- Automatic operation with level sensor; sludge removal machine reverses to prevent jamming
- Detachable design, easy installation
- Intelligent monitoring with automatic warning
- Self-cleaning brush and high-pressure automatic flushing
Technical Parameter
